RedLemon Corner Cabinet Model SF0523 User Manual

1. परिचय

Thank you for choosing the RedLemon Corner Cabinet Model SF0523. This modern fluted storage cabinet is designed to fit seamlessly into corner spaces, offering both aesthetic appeal and practical storage solutions. This manual provides detailed instructions for assembly, safe operation, and proper maintenance to ensure long-lasting enjoyment of your product.

2. सुरक्षितता माहिती

असेंब्ली आणि वापरण्यापूर्वी कृपया सर्व सुरक्षा इशारे आणि सूचना वाचा आणि समजून घ्या. या सूचनांचे पालन न केल्यास दुखापत होऊ शकते किंवा उत्पादनाचे नुकसान होऊ शकते.

• दोन व्यक्तींची असेंब्ली शिफारसित: For safety and ease of assembly, it is highly recommended that two adults assemble this cabinet.
• स्थिर पृष्ठभाग: Assemble the cabinet on a clean, flat, and stable surface to prevent scratching or damage.
• सर्व फास्टनर्स सुरक्षित करा: Ensure all screws, bolts, and connectors are securely tightened before using the cabinet. Periodically check and re-tighten as needed.
• वजन मर्यादा: शेल्फ् 'चे अव रुप जास्त भारित करू नका. स्थिरता राखण्यासाठी वजन समान प्रमाणात वितरित करा.
• मुलांची सुरक्षा: Keep small parts and packaging materials away from children during assembly. This product is not a toy.
• भिंतीचे अँकरिंग: If wall anchoring hardware is provided, it is strongly recommended to secure the cabinet to a wall to prevent tipping, especially in households with children.
• ओलावा टाळा: Do not expose the cabinet to excessive moisture or direct sunlight, as this can cause warping or discoloration.

3. भागांची यादी

Before beginning assembly, verify that all parts are present and undamaged. Refer to the assembly video for visual identification of each component.

• Wooden Panels (various shapes and sizes for top, bottom, sides, and shelves)
• Metal Legs/Base Frame
• Fluted Cabinet Doors
• दार हँडल्स
• चुंबकीय झेल
• शेल्फ पिन
• Various Screws (A, B, E, F, L)
• Cam Locks (A)
• Cam Dowels (B)
• Wood Dowels (D)
• Screw Covers (G, W)
• Metal Brackets (K2)
• Allen Wrench (P)
• Leg Screws (Q, R)

4. विधानसभा सूचना

Follow these step-by-step instructions for assembling your RedLemon Corner Cabinet. An assembly video is provided below for visual guidance.

चरण-दर-चरण असेंब्ली मार्गदर्शक:

1. Step 1: Prepare Side Panels (Video: 0:05 - 0:35)

   Insert 6 cam dowels (B) into the pre-drilled holes of the three narrow side panels (parts 3, 4, 5). Secure 8 screws (F) into the designated holes on these panels. Then, attach 6 cam locks (A) to connect these panels to form triangular sections.

2. Step 2: Attach Magnetic Catches to Base Panels (Video: 0:36 - 1:05)

   Insert 16 cam dowels (B) into the two larger base panels (parts 1, 2). Attach 1 magnetic catch (K1) to each base panel using 2 screws (E).
3. Step 3: Assemble First Side Section (Video: 1:06 - 1:12)

   Connect one narrow side panel (part 6) to one base panel (part 1) using 2 cam locks (A). Ensure the cam locks are tightened securely.

4. Step 4: Assemble Second Side Section (Video: 1:13 - 1:26)

   Connect another narrow side panel (part 5) to the partially assembled unit from Step 3 using 3 cam locks (A). This forms the initial corner structure.

5. Step 5: Assemble Third Side Section (Video: 1:27 - 1:35)

   Attach the third narrow side panel (part 6) to the growing structure using 3 cam locks (A). This completes the main body of the cabinet's frame.
6. Step 6: Attach Back Panels (Video: 1:36 - 1:43)

   Slide the two back panels (parts 7) into the grooves of the cabinet frame. Ensure they fit snugly.

7. Step 7: Attach Top Panel (Video: 1:44 - 1:59)

   Place the top panel (part 2) onto the assembled frame. Secure it using 8 cam locks (A) into the pre-drilled holes. Tighten all cam locks.

8. Step 8: Assemble and Attach Base Frame (Video: 2:00 - 2:22)

   Assemble the metal base frame (part 11) by connecting the legs (part 12) using 3 screws (Q) and 3 screws (R) with the provided Allen wrench (P). Once assembled, attach the base frame to the bottom of the cabinet using the appropriate screws.
9. Step 9: Install Screw Covers (Video: 2:23 - 2:40)

   Insert 22 screw covers (G) into all visible screw holes for a clean finish.

10. Step 10: Install Shelves (Video: 2:41 - 2:51)

    Insert 3 wood dowels (D) into the side panels at your desired height for the adjustable shelf. Place the shelf (part 27) onto these dowels.

11. Step 11: Attach Doors (Video: 2:52 - 3:32)

    Attach the door hinges (H) to the fluted doors (parts 8, 9) using 4 screws (L). Install the door handles (M) onto the doors using 4 screws (M). Then, attach the doors to the cabinet frame, ensuring they align with the magnetic catches.
12. Step 12: Secure Back Panels (Video: 3:33 - 3:50)

    Secure the back panels using 8 screws (E) and 8 plastic corner brackets (W) to ensure stability and prevent movement.

5. ऑपरेटिंग सूचना

The RedLemon Corner Cabinet is designed for simple and intuitive use.

• दरवाजे उघडणे/बंद करणे: Gently pull the door handles to open the fluted doors. The magnetic catches will hold the doors securely when closed.
• शेल्फ्स समायोजित करणे: The cabinet features one adjustable shelf. To adjust its height, carefully remove the shelf and reposition the wood dowels (D) into the desired pre-drilled holes on the side panels. Ensure the shelf is level and securely seated on the dowels before placing items on it.
• प्लेसमेंट: Position the cabinet in a corner to maximize space utilization. Ensure it is on a level surface to prevent wobbling.

6. काळजी आणि देखभाल

Proper care will help maintain the appearance and longevity of your RedLemon Corner Cabinet.

• स्वच्छता: मऊ सह पृष्ठभाग पुसणे, डीamp कापड. अपघर्षक क्लीनर किंवा कठोर रसायने टाळा, कारण ते फिनिशिंग खराब करू शकतात.
• गळती: ओलावाचे नुकसान किंवा डाग टाळण्यासाठी कोणतेही सांडलेले पदार्थ ताबडतोब पुसून टाका.
• सूर्यप्रकाश एक्सपोजर: लाकडी रंग फिकट किंवा रंगहीन होऊ नये म्हणून थेट सूर्यप्रकाशात जास्त काळ राहू नका.
• उष्णता: Do not place hot items directly on the cabinet surface. Use coasters or protective pads.
• नियमित तपासणी: Periodically inspect all fasteners and connections to ensure they remain tight. Re-tighten if necessary.

7. समस्या निवारण

If you encounter any issues with your cabinet, refer to these common solutions:

• डळमळीत कॅबिनेट: Ensure the cabinet is placed on a level surface. Check all cam locks and screws to confirm they are fully tightened. Adjust the leveling feet on the metal base if present.
• दरवाजे व्यवस्थित बंद न होणे: Check if the magnetic catches are aligned correctly. Ensure the door hinges are securely fastened and not loose. Verify that the cabinet frame is square and level.
• गहाळ भाग: If any parts are missing or damaged upon arrival, please contact customer support with your purchase details for assistance.

8. तपशील

9. उत्पादन संपलेview

Explore the design and features of the RedLemon Corner Cabinet with this product overview व्हिडिओ

प्रतिमा: The RedLemon Corner Cabinet, Model SF0523, showcasing its elegant natural oak finish and distinctive fluted doors, perfectly designed to complement any modern living space.
