MOVE SPEED Z70Pro

MOVE SPEED 2025 Upgrade Power Bank 70,000mAh 100W & 35W PD Fast Charger with Type C Retractable Cable

ब्रँड: MOVE SPEED | मॉडेल: Z70Pro

1. परिचय

Thank you for choosing the MOVE SPEED Z70Pro Power Bank. This device is designed to provide reliable and high-speed portable charging for a wide range of electronic devices, including smartphones, tablets, and laptops. With its massive 70,000mAh capacity, 100W Power Delivery (PD) output, and integrated 35W fast charger with a retractable Type-C cable, it offers unparalleled convenience and power for your daily needs and outdoor adventures.

सुरक्षित आणि इष्टतम कामगिरी सुनिश्चित करण्यासाठी उत्पादन वापरण्यापूर्वी कृपया हे मॅन्युअल काळजीपूर्वक वाचा. भविष्यातील संदर्भासाठी हे मॅन्युअल ठेवा.

2. सुरक्षितता माहिती

3. पॅकेज सामग्री

कृपया खालील वस्तूंसाठी पॅकेज तपासा:

MOVE SPEED Z70Pro Power Bank, 35W charger, and two USB-C cables

आकृती १: पॅकेज सामग्री संपलीview. The image displays the MOVE SPEED Z70Pro Power Bank, a white 35W wall charger with a retractable Type-C cable, and two separate USB-C to USB-C charging cables.

4. उत्पादनाची वैशिष्ट्ये

MOVE SPEED Z70Pro Power Bank in an outdoor setting, highlighting 70,000mAh capacity, 100W PD fast charging, 4-device simultaneous charging, and LED display.

Figure 4.1: Key Features of the Z70Pro Power Bank. The image shows the power bank with its side LED light illuminated, placed on a wooden table in an outdoor camping scene, emphasizing its large capacity and fast charging capabilities.

5. सेटअप

३.१ पॉवर बँकचे सुरुवातीचे चार्जिंग

Before first use, it is recommended to fully charge your MOVE SPEED Z70Pro Power Bank.

  1. Locate the integrated 35W PD Fast Charger on the side of the power bank.
  2. Extend the retractable Type-C cable from the charger.
  3. Plug the 35W charger directly into a standard wall outlet.
  4. The digital display on the power bank will show the charging progress. A full charge from empty takes approximately 5 hours.
Image showing the retractable Type-C cable extending from the 35W charger and plugging into a wall outlet.

Figure 5.1: Extending the Retractable Cable. This image illustrates how the integrated Type-C cable extends from the 35W wall charger for convenient use.

Close-up of the 35W GaN charger with a diagram of its internal GaN technology.

Figure 5.2: 35W GaN Charger Technology. This image highlights the compact design and advanced GaN technology of the integrated 35W charger.

6. ऑपरेटिंग सूचना

6.1 तुमचे डिव्हाइस चार्ज करणे

The MOVE SPEED Z70Pro Power Bank offers multiple output ports for charging various devices simultaneously.

  1. Using the 100W PD Output: For laptops, tablets, and other high-power devices, use a compatible USB-C to USB-C cable (one is included) and connect it to the 100W PD output port on the power bank and your device. This port supports up to 100W fast charging.
  2. Using the 35W Output (Retractable Cable): For smartphones and other devices compatible with Type-C, simply extend the integrated retractable Type-C cable from the 35W charger and plug it into your device. This port supports up to 35W fast charging.
  3. Using Other USB Ports: The power bank also features additional USB-A and USB-C ports for charging other devices. Connect your device's charging cable to the appropriate port.
  4. The digital display will indicate when a device is connected and charging.
Image demonstrating 100W Power Delivery charging a smartphone rapidly.

Figure 6.1: High-Speed 100W Power Delivery. This image illustrates the rapid charging capability of the 100W output, showing a phone charging from 30% to 70% in 20 minutes.

Image showing the 35W charger connected to various devices like a smartphone, tablet, and laptop, highlighting multi-protocol fast charging.

Figure 6.2: Multi-Protocol Fast Charging. This image demonstrates the versatility of the charger, capable of powering phones, tablets, and computers with various fast charging protocols.

6.2 Using the Emergency LED Light

The Z70Pro Power Bank includes a built-in LED light for emergency situations or general illumination.

  1. To turn on the LED light, locate the power button (or dedicated light button, if present) on the power bank and press it briefly.
  2. Subsequent brief presses will cycle through the light modes: High, Medium, Low, and SOS (Morse code for distress).
  3. To turn off the LED light, continue pressing the button until the light turns off, or press and hold the button for a few seconds.
Image showing the MOVE SPEED Z70Pro Power Bank with its LED light illuminated, demonstrating High, Medium, Low, and SOS modes.

Figure 6.3: Emergency Light with 4 Modes. This image displays the power bank's LED light functioning in an outdoor setting, illustrating its different brightness levels and SOS signal.

7. देखभाल

8. समस्या निवारण

समस्यासंभाव्य कारणउपाय
पॉवर बँक चार्ज होत नाहीCharger not properly connected; faulty cable/adapter; power bank battery depleted.Ensure charger is securely plugged into outlet and power bank. Try a different cable or adapter. Allow power bank to charge for a few minutes.
पॉवर बँकमधून डिव्हाइस चार्ज होत नाहीPower bank battery depleted; incompatible cable; device not properly connected; device requires more power than available.Recharge the power bank. Ensure the cable is securely connected to both the power bank and the device. Use a compatible cable. Check if your device's power requirements exceed the power bank's output.
स्लो चार्जिंगUsing a non-fast charging port/cable; device not supporting fast charging protocol; multiple devices charging simultaneously.Ensure you are using the 100W PD or 35W output ports with compatible cables. Verify your device supports the fast charging protocols (PD, QC). Charging multiple devices may reduce individual charging speeds.
एलईडी दिवा काम करत नाहीPower bank battery low; incorrect operation.Recharge the power bank. Refer to section 6.2 for correct operation of the LED light.

9. तपशील

वैशिष्ट्यतपशील
मॉडेलZ70Pro
क्षमता70,000mAh / 259Wh
Input (for Power Bank Charging)35W (via integrated charger)
Output 1 (USB-C PD)१०० वॅट पर्यंत वीज वितरण
Output 2 (Integrated Type-C Cable)२२.५W पर्यंत जलद चार्जिंग
इतर प्रदर्शन वैशिष्ट्येWireless (as per product specifications, though not explicitly detailed in features)
ASINB0F48NPMKJ
तारीख प्रथम उपलब्ध9 एप्रिल 2025
Image showing the compact size of the 35W charger compared to other plugs on a power strip.

Figure 9.1: Compact Size of the 35W Charger. This image highlights the small footprint of the integrated 35W charger, allowing it to fit easily on power strips.

10. हमी आणि समर्थन

MOVE SPEED products are designed and manufactured to the highest quality standards. For information regarding warranty coverage, technical support, or any product-related inquiries, please contact MOVE SPEED customer service through the retailer where you purchased the product or visit the official MOVE SPEED webसाइट

Please have your product model (Z70Pro) and ASIN (B0F48NPMKJ) ready when contacting support.

अधिक माहितीसाठी, तुम्ही भेट देऊ शकता MOVE SPEED Store on Amazon.
