SINGMOOD Portable Karaoke Machine S100 Instruction Manual

1. परिचय

The SINGMOOD S100 Portable Karaoke Machine is an all-in-one entertainment system designed for superior audio and visual performance. Featuring a 14.1-inch touchscreen, dual wireless UHF microphones, and a powerful 1000W Bluetooth PA speaker, this machine offers a seamless karaoke experience. Its advanced internal components ensure smooth operation and high-fidelity sound, making it ideal for various settings from home entertainment to outdoor gatherings.

Figure 1: The SINGMOOD S100 Portable Karaoke Machine with its two wireless microphones.

२. काय समाविष्ट आहे

Upon unboxing your SINGMOOD S100, please verify that all the following components are present:

• S-100 कराओके मशीन
• 2x UHF Microphones
• 2x Microphone Battery
• अडॅप्टर
• वापरकर्ता मॅन्युअल (हा दस्तऐवज)

Figure 2: Visual representation of the contents included in the product package.

3. प्रमुख वैशिष्ट्ये

The SINGMOOD S100 is equipped with several advanced features to enhance your karaoke and entertainment experience:

• 14.1" Touchscreen Display: A vibrant display for lyrics, video streaming, and intuitive navigation.
• ड्युअल वायरलेस UHF मायक्रोफोन: Provides crystal-clear sound with enhanced stability and long-range connectivity. These microphones are rechargeable via Type-C.
• 1000W Bluetooth PA Speaker: Delivers powerful, full-bodied sound for immersive audio.
• Advanced Internal Components: Powered by an RK3566 chip with 4GB RAM and 64GB ROM, ensuring smooth singing, fast loading, and seamless video streaming without lag.
• 32-bit Digital Audio Decoder Chip: For unparalleled clarity, depth, and richness in every note.
• Integrated App Store: Access and download popular applications like Apple Music, YouTube, Spotify, and Chrome directly from the device.
• कराओके मोड: A dedicated function to lower vocals in songs, transforming any track into a karaoke version with a single click.
• RGB Lighting Show: Dynamic lighting effects on the speaker create a vibrant party atmosphere.
• पोर्टेबल डिझाइन: Features a hand-carry handle and four transport wheels, making it as portable as a suitcase for easy transport.
• बहुमुखी कनेक्टिव्हिटी: Includes inputs for guitar, condenser microphone, headset, Live OTG, TF card, USB1, USB2, HDMI, and DC12V input.

आकृती 3: ओव्हरview of the internal technology stack ensuring lag-free performance.

Figure 4: The 32-bit Digital Audio Decoder Chip provides superior sound clarity.

Figure 5: Features of the True UHF Microphones.

Figure 6: The portable design with a hand-carry handle and transport wheels.

4. सेटअप

Follow these steps to set up your SINGMOOD S100 for the first time:

1. अनपॅक करा: पॅकेजिंगमधील सर्व घटक काळजीपूर्वक काढा. भविष्यातील साठवणूक किंवा वाहतुकीसाठी पॅकेजिंग जपून ठेवा.
2. वीज कनेक्शन: Connect the provided adapter to the DC12V INPUT port on the control panel and plug it into a power outlet. The machine can operate on battery power once charged.
3. मायक्रोफोन सेटअप: Insert the included 9V batteries into each wireless microphone. The microphones are pre-paired with the machine.
4. पॉवर चालू: Locate the red POWER ON/OFF switch on the control panel and switch it to the 'ON' position. The touchscreen will illuminate.
5. प्रारंभिक बूट: Allow the system to fully boot up. This may take a few moments.

5. ऑपरेटिंग सूचना

Navigate and utilize the various functions of your karaoke machine:

२. टचस्क्रीन नेव्हिगेशन

The 14.1-inch touchscreen serves as your primary interface. Tap on icons to launch applications or adjust settings. The main screen provides quick access to YouTube, Spotify, Bluetooth, My Application, Apple Music, Chrome, Play Store, MediaPlayer, and Settings.

Figure 7: The intuitive touchscreen interface for app access.

5.2. कराओके मोड

To activate karaoke mode and reduce original song vocals, press the dedicated 'KARAOKE M' button on the control panel. This allows your voice to be prominent over the instrumental track.

Figure 8: Activating Karaoke Mode.

5.3. Sound Effects and Controls

The control panel features various knobs and buttons for sound customization:

• आवाज नियंत्रण: Adjust the overall volume using the 'VOLUME+' and 'VOLUME-' knobs.
• Microphone Adjustments: Control microphone bass, treble, and echo using the dedicated 'MIC.BASS+', 'MIC.TREBLE+', and 'ECHO+' knobs.
• Sound Effects Buttons: Buttons for 'APPLAUSE', 'LAUGHTER', 'CHEER', and 'BOOING' are available for interactive fun.
• एलईडी नियंत्रण: Press the 'LED' button to cycle through or turn off the RGB lighting effects on the speaker.

आकृती 9: तपशीलवार view नियंत्रण पॅनेलचे.

5.4. External Connectivity

The S100 supports various external connections:

• HDMI आउटपुट: Connect an HDMI cable from the machine to a TV or external display for a larger screen experience.
• यूएसबी पोर्ट: Use USB1 and USB2 for connecting external storage devices or a mouse for easier navigation.
• ब्लूटूथ: Pair your smartphone or tablet via Bluetooth for wireless audio streaming.

6. देखभाल

To ensure the longevity and optimal performance of your SINGMOOD S100, follow these maintenance guidelines:

• स्वच्छता: Use a soft, dry cloth to clean the exterior surfaces. For the touchscreen, use a microfiber cloth specifically designed for electronics. Avoid abrasive cleaners or solvents.
• स्टोरेज: When not in use, store the machine in a cool, dry place away from direct sunlight and extreme temperatures. If storing for extended periods, ensure the battery is partially charged (around 50%) to preserve its lifespan.
• बॅटरी काळजी: Recharge the internal battery regularly, even if not frequently used, to prevent deep discharge.
• मायक्रोफोन काळजी: Store microphones in a safe place to prevent damage. Ensure they are charged when needed.

7. समस्या निवारण

If you encounter issues with your SINGMOOD S100, refer to the following common solutions:

• Feedback Noise: If you hear feedback noise from the speaker, lower the microphone treble, echo, and delay settings on the control panel. Adjusting the microphone's proximity to the speaker can also help.
• आवाज नाही: Ensure the volume is turned up on both the machine and any connected external devices. Check all cable connections (HDMI, audio inputs). Verify microphones are powered on and paired.
• स्क्रीन प्रतिसाद देत नाही: Try restarting the machine. If the issue persists, ensure the power connection is stable.
• कनेक्टिव्हिटी समस्या (ब्लूटूथ/वाय-फाय): Ensure the machine is within range of the Bluetooth device or Wi-Fi router. Restart both the machine and the connecting device.

8. तपशील

9. हमी आणि समर्थन

The SINGMOOD S100 Portable Karaoke Machine comes with a 10 वर्षाची वॉरंटी, as stated in the product title, ensuring long-term reliability and customer satisfaction. For any support needs, please contact the seller, Singmood, directly. Additionally, protection plans are available for purchase to extend coverage beyond the standard warranty period:

• ३ वर्षांची संरक्षण योजना: $४.९९ मध्ये उपलब्ध.
• ३ वर्षांची संरक्षण योजना: $४.९९ मध्ये उपलब्ध.
• पूर्ण संरक्षण: A monthly plan at $16.99/month covering all eligible past and future purchases.

For further assistance or inquiries, please refer to the contact information provided with your purchase or visit the official SINGMOOD support channels.
