TIATUA M9 इन्स्टंट प्रिंट किड्स कॅमेरा वापरकर्ता मॅन्युअल

परिचय

This manual provides comprehensive instructions for the TIATUA M9 Instant Print Kids Camera. Please read this manual carefully before using the camera to ensure proper operation and to maximize your experience.

उत्पादन संपलेview

प्रमुख वैशिष्ट्ये

• ४.३-इंच आयपीएस स्क्रीन: A larger, soft IPS screen for comfortable viewing आणि नेव्हिगेशन.
• 48 MP Photo Resolution: Capture high-quality images with a 48-megapixel lens.
• 1080p HD व्हिडिओ रेकॉर्डिंग: Record clear high-definition videos.
• झटपट मुद्रण: Print black and white photos directly from the camera without ink or toner.
• बहुकार्यात्मक: Includes photography, video recording, instant printing, fun frames, music playback, games, and a flashlight.
• दीर्घ बॅटरी आयुष्य: Equipped with a 1000 mAh battery, providing up to 4 hours of continuous use.
• ३२ जीबी मेमरी कार्ड समाविष्ट: Ampफोटो आणि व्हिडिओंसाठी स्टोरेज.
• सर्जनशील साधने: Comes with 5 colorful pens for customizing printed photos.

Image: The TIATUA M9 Instant Print Kids Camera highlighting its various functions like instant printing, 1080P video, MP3 player, puzzle games, 3.0-inch screen, 10x zoom, fun frames, and 32GB card.

प्रारंभ करणे

पॅकेज सामग्री

सर्व वस्तू उपलब्ध आहेत याची खात्री करण्यासाठी कृपया पॅकेज तपासा:

• TIATUA M9 Instant Print Kids Camera
• 32GB मायक्रो एसडी कार्ड
• Printing Paper Rolls (typically 3 rolls)
• यूएसबी चार्जिंग केबल
• डोरी/पट्टा
• Colorful Pens (5 pieces)
• वापरकर्ता मॅन्युअल (हा दस्तऐवज)

Image: The TIATUA M9 Instant Print Kids Camera in dark blue, displayed with its accessories including a 32GB memory card, colorful pens, three rolls of printing paper, a USB charging cable, and a decorative lanyard.

कॅमेरा चार्ज करत आहे

Before first use, fully charge the camera. Connect the included USB cable to the camera's charging port and to a USB power adapter (not included) or a computer's USB port. The charging indicator light will show the charging status.

मायक्रो एसडी कार्ड घालत आहे

Locate the Micro SD card slot on the side of the camera. Insert the 32GB Micro SD card (included) into the slot until it clicks into place. Ensure the camera is powered off before inserting or removing the card.

Loading Print Paper

Follow these steps to load the thermal printing paper:

1. पेपर स्लॉट उघडा: Gently push the latch or button to open the paper compartment cover.
2. Insert the Paper Roll: Place a new roll of thermal paper into the compartment. Ensure the paper feeds from the bottom of the roll and the end of the paper is facing outwards, ready to be pulled through the printing mechanism.
3. Pull Paper Out: Pull approximately 1 inch (2.5 cm) of paper out of the slot, ensuring it is straight.
4. कव्हर बंद करा: Close the paper compartment cover firmly until it clicks.

Image: A three-step visual guide demonstrating how to load the thermal printing paper into the TIATUA M9 Instant Print Kids Camera. Step 1 shows opening the paper slot, Step 2 shows inserting the paper roll in the correct direction, and Step 3 shows pulling out approximately 1 inch of paper before closing the compartment.

ऑपरेटिंग सूचना

मूलभूत नियंत्रणे

The camera features intuitive buttons for easy navigation:

• पॉवर बटण: Press and hold to turn the camera ON/OFF. Short press to switch modes or confirm selections.
• शटर बटण: फोटो काढण्यासाठी किंवा व्हिडिओ रेकॉर्डिंग सुरू/थांबवण्यासाठी दाबा.
• नेव्हिगेशन बटणे (वर/खाली/डावीकडे/उजवीकडे): Used to navigate menus, zoom in/out, or select options.
• ओके/कन्फर्म बटण: मेनूमधील निवडींची पुष्टी करते.
• मेनू बटण: Accesses camera settings and options.

फोटो काढत आहे

फोटो काढण्यासाठी:

1. कॅमेरा चालू करा.
2. Select the photo mode from the main menu.
3. Frame your shot using the 3.0-inch IPS screen.
4. (Optional) Use the navigation buttons to zoom in or out (up to 10x digital zoom).
5. Press the Shutter button to capture the image.

Image: The TIATUA M9 Instant Print Kids Camera's 3.0-inch screen displaying a live view, demonstrating 1080P HD video recording capability and 10x digital zoom functionality with examples of zoomed-in images.

रेकॉर्डिंग व्हिडिओ

व्हिडिओ रेकॉर्ड करण्यासाठी:

1. कॅमेरा चालू करा.
2. Select the video recording mode from the main menu.
3. Press the Shutter button once to start recording. A timer will appear on the screen.
4. Press the Shutter button again to stop recording. The video will be saved to the Micro SD card.

झटपट प्रिंटिंग

After taking a photo, you can instantly print it in black and white. The camera offers different printing densities:

• Low (1-3): Lighter print.
• Medium (4-5): Standard print.
• High (6-7): Darker print.

Select your desired density in the print settings before initiating the print. The camera uses thermal printing technology, requiring no ink cartridges.

Image: An illustration demonstrating the two printing modes (Grayscale Matrix and Grayscale Levels) and three printing densities (Low, Medium, High) available on the TIATUA M9 Instant Print Kids Camera, showing how image clarity changes with density settings.

Photo Frames and Filters

Enhance your photos with various built-in frames and filters. Access these options through the camera's menu while in photo mode. Select a frame or filter before taking a picture to apply it directly to the image and print.

Image: The TIATUA M9 Instant Print Kids Camera displaying various fun photo stickers and frames that can be applied to images, encouraging creative expression.

खेळ खेळणे

The camera includes several pre-installed puzzle games for entertainment. Navigate to the "Games" option in the main menu to select and play. Use the navigation buttons to control the games.

Image: A child interacting with the TIATUA M9 Instant Print Kids Camera, which displays various puzzle games on its screen, alongside icons for a music player and other interesting features.

Playback and Review

ला view your captured photos and videos, enter the "Playback" mode from the main menu. Use the navigation buttons to scroll through your media. Press the OK button to view एक फोटो किंवा व्हिडिओ प्ले करा.

देखभाल

कॅमेरा साफ करणे

To clean the camera body, use a soft, dry cloth. For the lens, use a specialized lens cleaning cloth. Do not use liquid cleaners or abrasive materials, as they may damage the camera.

स्टोरेज

Store the camera in a cool, dry place away from direct sunlight and extreme temperatures. When not in use for extended periods, ensure the battery is partially charged (around 50%) to prolong its lifespan.

समस्यानिवारण

सामान्य समस्या आणि उपाय

• कॅमेरा चालू होत नाही:
  • बॅटरी चार्ज झाली आहे याची खात्री करा. USB केबल वापरून कॅमेरा पॉवर स्रोताशी जोडा.
  • काही सेकंदांसाठी पॉवर बटण दाबा आणि धरून ठेवा.
• Cannot take photos/videos:
  • Check if the Micro SD card is inserted correctly and has sufficient free space.
  • Ensure the camera is in the correct mode (photo or video).
• Print quality is poor or no print:
  • Verify that the thermal paper is loaded correctly and not upside down.
  • Check if there is enough paper in the compartment.
  • Adjust the printing density settings in the camera menu.
  • Ensure the print head is clean (refer to cleaning instructions).
• Screen is frozen:
  • Try restarting the camera by holding the power button. If unresponsive, use a thin object to press the reset button (if available, usually a small pinhole).

तपशील

हमी आणि समर्थन

For warranty information and customer support, please refer to the contact details provided with your purchase or visit the official TIATUA webसाइट. कोणत्याही वॉरंटी दाव्यांसाठी तुमचा खरेदीचा पुरावा ठेवा.
