कॅंगारू लंडन बग्गी मॉडेल X1 वापरकर्ता मॅन्युअल

1. परिचय

The Cangaroo London Buggy is designed for comfort and convenience, suitable for children from six months of age up to a maximum weight of 15 kilograms (approximately three years old). It features a lightweight aluminum frame, an adjustable backrest with a secure harness system, and an adjustable footrest. The buggy is designed for easy folding and includes transparent wheels for smooth maneuverability.

2. सुरक्षितता माहिती

चेतावणी: या सूचनांचे पालन न केल्यास गंभीर दुखापत किंवा मृत्यू होऊ शकतो.

• बग्गीमध्ये तुमच्या मुलाला कधीही लक्ष न देता सोडू नका.
• Always use the 5-point safety harness to secure your child. Ensure it is correctly fitted and adjusted.
• वापरण्यापूर्वी सर्व लॉकिंग उपकरणे गुंतलेली असल्याची खात्री करा.
• Do not overload the storage basket. Maximum capacity is 3 kg.
• Do not use the buggy on stairs or escalators.
• The buggy is suitable for children from 6 months up to a maximum weight of 15 kg.
• Any load attached to the handle affects the stability of the buggy.
• Regularly check the buggy for loose parts, damaged components, or worn fabric. Discontinue use if any damage is found.
• Keep children clear of moving parts when making adjustments.

3. उत्पादनाची वैशिष्ट्ये

• Suitable for children from 6 months up to 15 kg.
• Lightweight aluminum frame.
• Adjustable backrest with harness system.
• Adjustable footrest.
• Foldable design for easy storage and transport.
• Transparent wheels with 360-degree swivel front wheels.
• Adjustable sun canopy with viewing window and accessory pocket.
• Large storage basket (max. 3 kg capacity).
• 5-point safety harness with padded straps.
• Removable front bar for easy child entry.
• Rear wheel brake for secure parking.

१. सेटअप आणि असेंब्ली

Follow these steps to assemble your Cangaroo London Buggy:

1. Unfolding the Buggy: Release the folding latch (if engaged). Hold the handle and lift the buggy upwards until the frame locks into place. Ensure both side locks are securely engaged.
2. चाके जोडणे: Insert the front and rear wheels into their respective slots until they click securely. Verify they are firmly attached by pulling on them.
3. छत जोडणे: Slide the canopy attachments onto the frame until they are secure. Adjust the canopy as desired.
4. Installing the Front Bar: Align the front bar with the attachment points on the frame and push until it clicks into place. Ensure it is secure before use.

5. ऑपरेटिंग सूचना

5.1 Adjusting the Backrest

To recline the backrest, locate the adjustment strap or lever behind the seat. Squeeze the buckle or lever and gently lower the backrest to the desired position. To raise it, push the backrest upwards while guiding the strap or lever until it locks into place.

5.2 Adjusting the Footrest

The footrest can be adjusted by pressing the buttons on either side of the footrest and moving it up or down to the desired angle. Release the buttons to lock it in position.

5.3 Using the 5-Point Safety Harness

Place your child in the seat. Bring the shoulder straps over your child's shoulders and the waist straps around their waist. Insert the two buckle prongs into the central buckle until they click. Adjust the straps for a snug, secure fit. To release, press the button on the central buckle.

5.4 Engaging the Brake

To engage the brake, press down firmly on the brake pedal located near the rear wheels. Ensure the buggy is stationary before releasing your grip. To release the brake, lift the pedal upwards.

5.5 Folding the Buggy

Ensure the backrest is in an upright position and the canopy is retracted. Locate the folding mechanism (often a button or lever on the handle or frame). Activate the mechanism and push the handle forward or pull it upwards, following the buggy's natural folding motion until it locks into a compact position.

6. देखभाल आणि काळजी

6.1 स्वच्छता

• फॅब्रिक भाग: The fabric (60% cotton, 40% linen) can be spot cleaned with a damp cloth and mild soap. Do not machine wash or tumble dry. Allow to air dry completely.
• फ्रेम: अॅल्युमिनियम फ्रेम मऊ, ड ने पुसून टाका.amp कापड नख वाळवा.
• चाके: Periodically clean the wheels to remove dirt and debris. Lubricate moving parts with a silicone-based spray if necessary.

५.८.१ स्टोरेज

Store the buggy in a clean, dry place away from direct sunlight and extreme temperatures. Ensure it is completely dry before storing to prevent mold or mildew.

7. समस्या निवारण

• Buggy does not fold/unfold smoothly: Check for any obstructions in the folding mechanism. Ensure the backrest is fully upright before attempting to fold. Lubricate moving parts if stiff.
• Wheels are stiff or squeaky: Clean the wheels and axles to remove dirt. Apply a small amount of silicone lubricant to the moving parts of the wheels.
• Harness is difficult to buckle/unbuckle: Ensure the buckle prongs are aligned correctly. Clean any debris from the buckle mechanism.
• Brake is not engaging/disengaging: Check for obstructions around the brake mechanism. Ensure the brake pedal is fully depressed or lifted.

8. तपशील

9. हमी आणि समर्थन

For warranty information, please refer to the documentation provided at the time of purchase or contact your retailer. For product support or spare parts, please contact Cangaroo customer service or your local distributor. Keep your proof of purchase for any warranty claims.
