LG F14R50WHS फ्रंट-लोड वॉशिंग मशीन वापरकर्ता मॅन्युअल

1. उत्पादन संपलेview

This manual provides essential information for the safe and efficient operation of your LG F14R50WHS front-load washing machine. Please read it thoroughly before using the appliance and keep it for future reference.

The LG F14R50WHS washing machine features advanced technologies such as AI Direct Drive for intelligent fabric care and 6 Motion Direct Drive for optimized washing movements. It offers an 11 kg washing capacity and a spin speed of 1400 RPM, making it suitable for large households. The hygienic steam function helps eliminate allergens and ensures a deeper clean.

2. सुरक्षितता माहिती

आग, विजेचा धक्का किंवा व्यक्तींना दुखापत होण्याचा धोका कमी करण्यासाठी हे उपकरण वापरताना नेहमीच मूलभूत सुरक्षा खबरदारी पाळा.

• विद्युत सुरक्षा: Ensure the appliance is properly grounded. Do not use an extension cord or adapter. Unplug the washing machine before cleaning or performing any maintenance.
• पाण्याची सुरक्षा: Ensure water inlet hoses are securely connected to prevent leaks. Do not operate the machine if there is a water leak.
• बाल सुरक्षा: उपकरण चालवताना मुलांना उपकरणापासून दूर ठेवा. मुलांना उपकरणावर किंवा उपकरणात खेळू देऊ नका.
• ज्वलनशील साहित्य: Do not wash items that have been soiled with flammable substances (e.g., cooking oil, gasoline) as this may result in fire or explosion.
• स्थापना: The appliance must be installed by a qualified technician. Ensure the appliance is level and stable to prevent excessive vibration and noise.

3. सेटअप आणि स्थापना

3.1 अनपॅक करणे

Carefully remove all packaging materials, including the base packaging and any protective films. Retain packaging for transport if needed.

3.2 स्थान आवश्यकता

Install the washing machine on a firm, level surface. Ensure there is adequate space for water inlet and drain hoses, and power connection. Avoid direct sunlight or extreme temperatures.

४.३ पाण्याच्या नळ्या जोडणे

गरम आणि थंड पाण्याच्या इनलेट होसेस मशीनच्या मागील बाजूस असलेल्या संबंधित व्हॉल्व्हशी आणि तुमच्या घरातील पाणी पुरवठ्याशी जोडा. गळती रोखण्यासाठी कनेक्शन घट्ट असल्याची खात्री करा.

४.४ ड्रेन होज जोडणे

Securely attach the drain hose to a standpipe or laundry tub, ensuring it is properly routed to prevent kinks or blockages.

3.5 वीज जोडणी

पॉवर कॉर्ड ग्राउंड केलेल्या इलेक्ट्रिकल आउटलेटमध्ये प्लग करा. एक्सटेंशन कॉर्ड वापरू नका.

६.३ उपकरण समतल करणे

Adjust the leveling feet at the bottom of the washing machine until the appliance is perfectly level and stable. This prevents excessive vibration during operation.

4. ऑपरेटिंग सूचना

४.१ लाँड्री लोड करणे

Open the door and load items loosely into the drum. Do not overload the machine. Close the door firmly.

४.३ डिटर्जंट आणि अ‍ॅडिटिव्ह्ज जोडणे

डिटर्जंट डिस्पेंसर ड्रॉवर बाहेर काढा. मुख्य वॉश कंपार्टमेंटमध्ये योग्य प्रमाणात डिटर्जंट आणि त्याच्या नियुक्त केलेल्या कंपार्टमेंटमध्ये फॅब्रिक सॉफ्टनर घाला. ड्रॉवर हळूवारपणे बंद करा.

४.३ कार्यक्रम निवडणे

Turn the program selector dial to choose the desired wash cycle. The display will show the default settings for the selected program.

४.५ समायोजन पर्याय

Use the option buttons on the control panel to adjust temperature, spin speed, or add special functions like pre-wash or extra rinse, if available for the selected program.

4.5 सायकल सुरू करणे

वॉश सायकल सुरू करण्यासाठी स्टार्ट/पॉज बटण दाबा.

4.6 Pausing/Canceling a Cycle

To pause a cycle, press the Start/Pause button. To cancel, press and hold the Start/Pause button for a few seconds until the machine resets.

4.7 सायकलचा शेवट

The machine will signal when the cycle is complete. Remove laundry promptly to prevent wrinkles.

5. Programs and Features

Your LG F14R50WHS washing machine offers a variety of programs and features designed for optimal fabric care.

• एआय डायरेक्ट ड्राइव्ह: Intelligently detects fabric type and load weight to optimize wash patterns, ensuring gentle yet effective cleaning.
• ६ मोशन डायरेक्ट ड्राइव्ह: Utilizes six distinct drum motions (Stepping, Filtration, Scrubbing, Tumble, Rolling, Swing) to provide a tailored wash for different fabric types.
• Hygienic Steam: A special steam function that helps remove allergens and bacteria from clothes, providing a deeper and more hygienic clean.
• Anti-Allergy Cycle: Specifically designed to reduce common allergens such as dust mites and pollen by up to 99.9%.
• क्षमता: 11 kg washing capacity, suitable for large loads and bulky items.
• स्पिन गती: Maximum 1400 RPM for efficient water extraction, reducing drying time.

Available Wash Programs:

• एआय वॉश
• कापूस
• 40°C मिक्स करा
• सिंथेटिक्स
• विरोधी ऍलर्जी
• नाजूक
• जलद 14
• स्वच्छ धुवा + फिरवा
• स्पोर्ट्सवेअर

6. देखभाल आणि स्वच्छता

नियमित देखभालीमुळे तुमच्या वॉशिंग मशीनची कार्यक्षमता वाढते आणि त्याचे आयुष्य वाढते.

६.२ डिटर्जंट डिस्पेंसर साफ करणे

Periodically remove and clean the detergent dispenser drawer to prevent residue buildup. Rinse it under running water and dry thoroughly before reinserting.

६.१ ड्रम साफ करणे

Run a 'Tub Clean' or 'Drum Clean' cycle (if available) regularly to remove detergent residue and odors from the drum. Alternatively, run an empty hot wash cycle with a cup of white vinegar.

६.३ ड्रेन पंप फिल्टर साफ करणे

Locate the drain pump filter access panel at the bottom front of the machine. Open the panel, place a shallow tray underneath to catch water, and carefully unscrew the filter. Clean any lint or debris and rinse under water. Reinsert and close the panel.

6.4 बाह्य साफ करणे

मऊ सह बाह्य पृष्ठभाग पुसणे, डीamp कापड अपघर्षक क्लीनर किंवा सॉल्व्हेंट्स वापरू नका.

7. समस्या निवारण

सेवेशी संपर्क साधण्यापूर्वी, खालील सामान्य समस्या आणि उपाय पहा:

• शक्ती नाही: पॉवर कॉर्ड सुरक्षितपणे जोडलेला आहे का आणि सर्किट ब्रेकर ट्रिप झाला आहे का ते तपासा.
• Water Not Filling: Ensure water taps are fully open and water inlet hoses are not kinked. Check if the water pressure is sufficient.
• पाणी न निघणे: Check if the drain hose is kinked or blocked. Clean the drain pump filter for any obstructions.
• जास्त कंपन/आवाज: Ensure the washing machine is level and all transit bolts have been removed during installation. Distribute laundry evenly in the drum.
• त्रुटी कोड: Refer to the full user manual (available on the LG website) for specific error code explanations and solutions.

8. तपशील

9. हमी आणि समर्थन

Your LG F14R50WHS washing machine comes with a manufacturer's warranty. For detailed warranty information, terms, and conditions, please refer to the warranty card included with your product or visit the official LG webसाइट

For technical support, service requests, or to purchase genuine LG spare parts, please contact LG Customer Service or visit their official support portal. Contact information can typically be found on the LG webसाइट किंवा तुमच्या उत्पादन दस्तऐवजीकरणात.
