1. परिचय
Thank you for choosing the VATOS 1:12 4WD 2.4GHz High-Speed RC Off-Road Buggy, Model VL-9156. This remote control vehicle is designed for thrilling off-road experiences, featuring a powerful 4WD system, high-speed capabilities up to 46 km/h, and IPX4 water resistance. This manual provides essential information for safe operation, setup, maintenance, and troubleshooting to ensure optimal performance and longevity of your RC buggy.
Image 1.1: The VATOS RC Buggy demonstrating its high-speed capability.
2. सुरक्षितता खबरदारी
Read and understand all safety instructions before operating the RC buggy. Failure to follow these instructions may result in injury or damage to the product.
- प्रौढ पर्यवेक्षण: This product is recommended for users aged 14 and above. Adult supervision is advised for younger users.
- ऑपरेटिंग वातावरण: Operate the RC buggy in open areas, away from people, pets, vehicles, and obstacles. Avoid public roads.
- पाणी प्रतिकार: The buggy has an IPX4 water resistance level, meaning it is protected against splashing water. Avoid submerging the vehicle in water or operating it in heavy rain.
- हलणारे भाग: Keep fingers, hair, and loose clothing away from moving parts such as wheels and gears to prevent injury.
- बॅटरी सुरक्षा: Use only the specified Li-ion battery and charger. Do not overcharge, short-circuit, or puncture batteries. Dispose of batteries properly.
- उष्णता: The motor and battery may become hot during operation. Allow them to cool before handling or recharging.
3. पॅकेज सामग्री
सर्व वस्तू काळजीपूर्वक अनपॅक करा आणि तुम्हाला खालील घटक मिळाले आहेत याची पडताळणी करा:
- VATOS 1:12 Scale RC Off-Road Buggy (Model VL-9156)
- 2.4GHz रिमोट कंट्रोलर
- Rechargeable Li-ion Battery (7.4V 1500mAh)
- यूएसबी चार्जिंग केबल
- सूचना पुस्तिका (हा दस्तऐवज)
प्रतिमा 3.1: ओव्हरview of the VATOS RC Buggy and its included accessories.
4. घटक संपलेview
4.1 RC Buggy
The VATOS RC Buggy features a durable chassis, independent suspension, and high-quality rubber tires for superior off-road performance. It is powered by a high-performance motor and a Li-ion battery.
प्रतिमा २: तपशीलवार view of the RC Buggy's chassis, highlighting key components and dimensions.
4.2 रिमोट कंट्रोलर
The 2.4GHz remote controller provides precise control over the buggy's movements, including forward, backward, left, and right steering. It also features speed and steering trim adjustments.
Image 4.2: The RC Buggy, remote controller, and battery.
5. सेटअप
5.1 Charging the RC Buggy Battery
- Connect the Li-ion battery to the USB charging cable.
- Plug the USB charging cable into a standard USB power adapter (e.g., phone charger, computer USB port).
- The charging indicator on the USB cable will show the charging status (refer to the charger's specific instructions for light indications).
- Charging typically takes approximately 3-4 hours for a full charge. Do not leave the battery unattended while charging.
5.2 Installing the RC Buggy Battery
- Remove the body shell of the RC buggy by detaching the body clips.
- बॅटरी कंपार्टमेंट उघडा.
- Connect the fully charged Li-ion battery to the vehicle's power connector.
- Place the battery securely within the compartment and close the cover.
- Reattach the body shell using the clips.
5.3 Installing Remote Controller Batteries
- रिमोट कंट्रोलरच्या मागील बाजूस असलेल्या बॅटरीचा डबा उघडा.
- Insert 3x AA batteries (not included) into the compartment, ensuring correct polarity (+/-).
- बॅटरी कंपार्टमेंट कव्हर सुरक्षितपणे बंद करा.
6. ऑपरेटिंग सूचना
४.१ पॉवर चालू आणि जोडणी
- Turn on the remote controller first. The indicator light will flash.
- Turn on the RC buggy. The indicator light on the buggy will also flash.
- Once the lights on both the remote and the buggy become solid, the pairing process is complete, and the vehicle is ready for operation.
५.१ ड्रायव्हिंग नियंत्रणे
- थ्रॉटल ट्रिगर: Pull the trigger to move forward. Push the trigger to brake or reverse.
- सुकाणू चाक: Turn the wheel left to steer left, and right to steer right.
- स्पीड स्विच: The remote controller may feature a speed switch (often labeled 'High/Low' or similar) to adjust the maximum speed of the buggy.
- सुकाणू ट्रिम: Use the steering trim dial to adjust the steering if the buggy pulls to one side when the steering wheel is centered.
- थ्रॉटल ट्रिम: Use the throttle trim dial to adjust the throttle if the buggy moves slightly forward or backward when the trigger is in the neutral position.
Image 6.1: The RC Buggy's performance across diverse terrains.
Image 6.2: The RC Buggy's 4WD system in action on an incline.
7. देखभाल
7.1 स्वच्छता
- After each use, especially in dirty or dusty conditions, gently clean the buggy with a soft brush or cloth to remove dirt and debris.
- Do not use water directly on electronic components. For light cleaning, a slightly damp cloth can be used on the body.
५.८.१ स्टोरेज
- When not in use, store the RC buggy and remote controller in a cool, dry place, away from direct sunlight and extreme temperatures.
- Remove batteries from both the RC buggy and the remote controller before long-term storage to prevent leakage.
7.3 बॅटरी काळजी
- रिचार्ज करण्यापूर्वी बॅटरी नेहमी थंड होऊ द्या.
- Do not fully discharge the Li-ion battery, as this can reduce its lifespan.
- जर जास्त काळ साठवत असाल तर बॅटरी अंदाजे ५०% क्षमतेपर्यंत चार्ज करा.
8. समस्या निवारण
If you encounter issues with your VATOS RC Buggy, refer to the following common problems and solutions:
| समस्या | संभाव्य कारण | उपाय |
|---|---|---|
| Buggy does not respond to remote. | Low battery in buggy or remote; Not paired; Out of range. | Charge buggy battery; Replace remote batteries; Re-pair the devices; Operate within range. |
| Buggy moves slowly or lacks power. | Low buggy battery; Motor or gears obstructed. | Charge buggy battery; Check for debris in motor/gears and clean. |
| Buggy pulls to one side. | Steering trim needs adjustment; Damaged steering components. | Adjust steering trim on the remote; Inspect steering linkage for damage. |
| लहान ऑपरेटिंग वेळ. | Battery not fully charged; Old or damaged battery. | Ensure battery is fully charged; Consider replacing the battery if it's old or damaged. |
9. तपशील
Detailed technical specifications for the VATOS 1:12 4WD 2.4GHz High-Speed RC Off-Road Buggy (Model VL-9156):
- मॉडेलचे नाव: VL-9156
- ब्रँड: व्हॅटोस
- स्केल: १६:१०
- परिमाण (L x W x H): २०८.९१ x १५६ x १०० सेमी (अंदाजे ८२.२ x ६१.४ x ३९.४ इंच)
- वजन: १.२५ किलो (अंदाजे २.७५ पौंड)
- साहित्य: प्लास्टिक
- ड्राइव्ह सिस्टम: ४-व्हील ड्राइव्ह (४WD)
- वारंवारता: 2.4 GHz
- कमाल गती: 46 किमी/ता पर्यंत
- Battery Type (Vehicle): लिथियम-आयन (ली-आयन)
- Battery Capacity (Vehicle): 7.4V 1500mAh (typically)
- बॅटरी प्रकार (रिमोट कंट्रोल): एए बॅटरी (समाविष्ट नाही)
- जलरोधक पातळी: IPX4 (स्प्लॅश-प्रूफ)
- विशेष वैशिष्ट्ये: Independent suspension, high-performance motor, high-quality rubber tires, cross-country capabilities.
Image 9.1: The RC Buggy showcasing its speed and scale.
Image 9.2: The RC Buggy's IPX4 water resistance.
10. हमी आणि समर्थन
Information regarding product warranty and customer support was not provided in the available data. For warranty details, technical assistance, or spare parts inquiries, please refer to the product packaging or contact VATOS customer service directly through their official webज्या साइटवर किंवा किरकोळ विक्रेत्याकडे उत्पादन खरेदी केले होते.
