1. परिचय
This instruction manual provides comprehensive guidance for the safe and effective use of your Inkbird ITC-308 Digital Temperature Controller and IHC-200 Digital Humidity Controller. These devices are designed to precisely control temperature and humidity in various environments, ensuring optimal conditions for your specific needs. Please read this manual thoroughly before operation and retain it for future reference.
2. उत्पादन संपलेview
The Inkbird ITC-308 is a plug-and-play digital temperature controller capable of simultaneously controlling heating and cooling devices. The Inkbird IHC-200 is a plug-and-play digital humidity controller designed for humidification and dehumidification. Together, they offer a complete solution for environmental control.
Image 2.1: Inkbird ITC-308 and IHC-200 controllers.
प्रमुख वैशिष्ट्ये:
- ITC-308: Digital thermostat with dual relay output for simultaneous heating and cooling control.
- ITC-308: Features an IP68 NTC stainless steel probe (2m), temperature calibration, compressor delay protection, and alarm functions for temperature limits or sensor failure.
- IHC-200: Digital hygrostat with dual relay output for simultaneous humidification and dehumidification.
- IHC-200: Includes a 2m humidity probe for accurate measurement and control.
- Suitable for various applications including brewing, aquariums, terrariums, plant cultivation, and reptile incubators.
3. तपशील
ITC-308 Temperature Controller:
| वीज पुरवठा | 220V AC, 50/60Hz |
| वीज वापर | 3W पेक्षा कमी |
| तापमान नियंत्रण श्रेणी | -50°C ते 120°C (-58°F ते 248°F) |
| तापमान रिझोल्यूशन | 0.1°C |
| तापमान अचूकता | ±1°C |
| सेन्सर प्रकार | NTC sensor (2m cable) |
| रिले आउटपुट | Heating: 10A/220V, Cooling: 10A/220V |
| Total Power Value | 2200W / 220V |
IHC-200 Humidity Controller:
| वीज पुरवठा | 220V AC, 50/60Hz |
| वीज वापर | 3W पेक्षा कमी |
| आर्द्रता मोजण्याची श्रेणी | 5% ते 99% आरएच |
| आर्द्रता नियंत्रण श्रेणी | 10% ते 99% आरएच |
| आर्द्रता निराकरण | 1% आरएच |
| आर्द्रता अचूकता | ±3% RH |
| सेन्सर प्रकार | Humidity sensor (2m cable) |
| रिले आउटपुट | Humidification: 10A/220V, Dehumidification: 10A/220V |
| Total Power Value | 2200W / 220V |
4. सेटअप आणि स्थापना
Before connecting any devices, ensure both the ITC-308 and IHC-200 controllers are unplugged from the power source.
4.1 Connecting the ITC-308 Temperature Controller
- Plug the temperature probe into the designated port on the ITC-308.
- Connect your heating device (e.g., heat mat, ceramic heater) to the 'Heating' outlet.
- Connect your cooling device (e.g., fan, chiller) to the 'Cooling' outlet.
- Position the temperature probe in the environment where temperature needs to be monitored and controlled.
- Plug the ITC-308 controller into a power outlet.
Image 4.1: ITC-308 Temperature Controller connections.
4.2 Connecting the IHC-200 Humidity Controller
- Plug the humidity probe into the designated port on the IHC-200.
- Connect your humidification device (e.g., fogger, humidifier) to the 'Work 1' outlet.
- Connect your dehumidification device (e.g., dehumidifier, fan) to the 'Work 2' outlet.
- Position the humidity probe in the environment where humidity needs to be monitored and controlled.
- Plug the IHC-200 controller into a power outlet.
Image 4.2: IHC-200 Humidity Controller connections.
२.३ सामान्य कनेक्शन आकृती
प्रतिमा ५.२: उदा.ample applications for the controllers.
5. ऑपरेटिंग सूचना
5.1 ITC-308 Temperature Controller Operation
The ITC-308 allows you to set a desired temperature range. The heating device will activate when the temperature drops below the set point, and the cooling device will activate when it rises above the set point.
- View तापमान सेट करा: Press the 'SET' button once to view वर्तमान सेट तापमान.
- तापमान सेट करा: Press and hold the 'SET' button for 3 seconds until the display flashes. Use the Up/Down arrows to adjust the desired temperature. Press 'SET' again to confirm.
- तापमान कॅलिब्रेशन: Refer to the full user manual for advanced settings like temperature calibration and compressor delay.
Video 5.1: Instructions for setting temperature on the ITC-308 controller.
5.2 IHC-200 Humidity Controller Operation
The IHC-200 allows you to maintain a specific humidity level. The humidification device will activate when humidity drops below the set point, and the dehumidification device will activate when it rises above the set point.
- View आर्द्रता सेट करा: Press the 'SET' button once to view the current set humidity.
- आर्द्रता सेट करा: Press and hold the 'SET' button for 3 seconds until the display flashes. Use the Up/Down arrows to adjust the desired humidity. Press 'SET' again to confirm.
- आर्द्रता कॅलिब्रेशन: Refer to the full user manual for advanced settings like humidity calibration.
Video 5.2: Instructions for setting humidity on the IHC-200 controller.
6. देखभाल
Regular maintenance ensures the longevity and accuracy of your controllers.
- स्वच्छता: Wipe the controller units with a soft, dry cloth. Do not use abrasive cleaners or immerse the units in water.
- तपासणी काळजी: Keep the temperature and humidity probes clean and free from debris. Avoid bending or damaging the probe cables.
- स्टोरेज: When not in use, store the controllers in a cool, dry place away from direct sunlight and extreme temperatures.
7. समस्या निवारण
If you encounter issues with your Inkbird controllers, refer to the following common problems and solutions:
| समस्या | संभाव्य कारण | उपाय |
|---|---|---|
| Display shows 'HHH' or 'LLL' | Sensor error or out of range. | Check sensor connection. Ensure the environment's temperature/humidity is within the device's operating range. Replace sensor if damaged. |
| Device not turning on/off as expected | Incorrect settings (set point, differential), device malfunction, or power issue. | Verify set point and differential settings. Check power supply to the controller and connected devices. Test devices independently. |
| Alarm constantly sounding | Temperature/humidity outside alarm limits, or alarm settings are too narrow. | Adjust alarm limits to suit your environment. Check if the environment is stable. |
For further assistance, please contact Inkbird customer support.
8. हमी आणि समर्थन
Inkbird products are designed for reliability and performance. While specific warranty details may vary by region and retailer, Inkbird generally offers a limited warranty against defects in materials and workmanship.
For warranty claims, technical support, or any questions regarding your ITC-308 or IHC-200 controllers, please visit the official Inkbird website or contact their customer service department directly. Ensure you have your product model number and purchase information available when seeking support.
