क्रिएटिव्ह इन्स्पायर S2 ब्लूटूथ वायरलेस मल्टीमीडिया स्पीकर सिस्टम वापरकर्ता मॅन्युअल

उत्पादन संपलेview

The Creative Inspire S2 Bluetooth Wireless Multimedia Speaker System provides high-quality audio through its two satellite speakers and a subwoofer, with the added convenience of Bluetooth wireless connectivity. This system is designed for use with computers and other Bluetooth-enabled devices, offering a versatile audio solution.

Image: The Creative Inspire S2 system, showing the central subwoofer unit, two compact satellite speakers, and a small USB Bluetooth transmitter. The satellite speakers are white with black grilles, and the subwoofer is black.

बॉक्स सामग्री

पॅकेजिंगमध्ये सर्व घटक आहेत याची खात्री करा:

• दोन सॅटेलाइट स्पीकर्स
• एक सबवूफर
• यूएसबी ब्लूटूथ ट्रान्समीटर
• युनिव्हर्सल पॉवर अडॅप्टर
• जलद सुरुवात मार्गदर्शक (तपशीलवार सूचनांसाठी या मॅन्युअलचा संदर्भ घ्या)
• Warranty/Technical Support Leaflet

सेटअप सूचना

१. शारीरिक संबंध

1. पोझिशनिंग: Place the subwoofer on the floor or a sturdy surface. Position the two satellite speakers on either side of your computer monitor or listening area for optimal stereo separation.
2. सॅटेलाइट स्पीकर्स कनेक्ट करा: Connect the cables from the satellite speakers to the corresponding ports on the back of the subwoofer. Ensure a secure connection.
3. वीज कनेक्ट करा: Plug the universal power adapter into the subwoofer's power input, then connect the adapter to a wall outlet.

2. Bluetooth Connection (Wireless Audio)

For Computers (using included USB Bluetooth Transmitter):

1. Insert Transmitter: Plug the included USB Bluetooth transmitter into an available USB port on your computer. Your computer may automatically install necessary drivers.
2. Power On Speakers: Ensure the speaker system is powered on. The power button is typically located on one of the satellite speakers. A green light should indicate power.
3. स्वयंचलित जोडणी: The speaker system and USB transmitter should automatically pair. A blue light on the satellite speaker will indicate a successful Bluetooth connection.
4. ऑडिओ आउटपुट निवडा: On your computer, navigate to your sound settings and select the "Creative Inspire S2" or similar Bluetooth audio device as your default playback device.

For Other Bluetooth Devices (e.g., Smartphones, Tablets, Laptops with built-in Bluetooth):

1. Power Off Speakers: Ensure the speaker system is turned off.
2. जोडणी मोड प्रविष्ट करा: With the speakers off, press and hold the '+' (volume up) button on the satellite speaker. Continue holding until a blue light begins to flash rapidly. This indicates the speakers are in pairing mode.
3. डिव्हाइसवर ब्लूटूथ सक्षम करा: तुमच्या स्मार्टफोन, टॅबलेट किंवा लॅपटॉपवर, ब्लूटूथ सेटिंग्जमध्ये जा आणि ब्लूटूथ सक्षम असल्याची खात्री करा.
4. Select "Inspire S2": In the list of available devices, select "Inspire S2" (or similar). If prompted for a passcode, enter "0000" (four zeros).
5. कनेक्शनची पुष्टी करा: Once paired, the blue light on the satellite speaker will become solid, indicating a successful connection.

3. Wired Connection (Auxiliary Input)

The Inspire S2 system also supports a wired connection for devices without Bluetooth or for a direct audio link.

1. ऑडिओ केबल कनेक्ट करा: Connect a 3.5mm audio cable (not included) from the audio output of your device (e.g., MP3 player, laptop headphone jack) to the "Audio In" port on the side of the satellite speaker.
2. Power On Speakers: स्पीकर सिस्टम चालू असल्याची खात्री करा.
3. प्लेबॅक: Begin audio playback from your connected device. The system will automatically prioritize the wired input if a cable is connected.

ऑपरेटिंग सूचना

पॉवर चालू/बंद

• To power on the system, press the power button located on one of the satellite speakers. A green LED will illuminate.
• To power off, press the power button again. The LED will turn off.

आवाज नियंत्रण

• Use the '+' and '-' buttons on the satellite speaker to adjust the system's volume.
• You can also control the volume from your connected Bluetooth device or computer.

ऑडिओ प्लेबॅक

• Once connected via Bluetooth or auxiliary cable, simply start playing audio from your source device.
• Ensure the volume on both the speaker system and your source device is adjusted appropriately.

देखभाल

• स्वच्छता: Use a soft, dry cloth to clean the surfaces of the speakers and subwoofer. Avoid using liquid cleaners or abrasive materials.
• प्लेसमेंट: Ensure the speakers are placed on stable surfaces to prevent accidental falls. Avoid placing them in direct sunlight, near heat sources, or in excessively humid environments.
• वायुवीजन: Do not block the ventilation openings on the subwoofer to ensure proper airflow and prevent overheating.
• केबल व्यवस्थापनः Keep cables organized and untangled to prevent damage and tripping hazards.

समस्यानिवारण

तपशील

हमी आणि समर्थन

For warranty information and technical support, please refer to the warranty/technical support leaflet included in your product packaging. You may also visit the official Creative website for the latest support resources, FAQs, and contact information.

ऑनलाइन समर्थन: www.creative.com/support
